Clutch Facing Weaving Machine Sj414 Shipping Cost and Estimated Delivery Time
Product Details:
| Place of Origin: | China |
| Brand Name: | TOSUN |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | Peak Season Lead Time: within 15 workdays, Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T, D/P, PayPal, Western Union, Small-amount payment |
| Supply Ability: | 1000PCS/Year |
|
Detail Information |
|||
| Model NO.: | SJ414 | Classification: | Friction Clutch |
|---|---|---|---|
| Usage: | Car, Tractors, Motorcycle | Voltage: | 380V |
| Transport Package: | Wooden Case | Specification: | 2040x780x1260mm |
| Trademark: | TOSUN | Origin: | Dalian |
| Supply Ability: | 1000PCS/Year | Package Size: | 2040.00cm * 780.00cm * 1260.00cm |
| Package Gross Weight: | 760.000kg | After-sales Service: | Yes |
| Warranty: | 1 Year | Part: | Clutch Facing |
| Customization: | Available | Customized Request | Shipping Cost: | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. | ||
Product Description
Usage Range
Equipment Specification
| Description | Specification |
| Plate type 1 diameter | raw facing inside diameter ≥Φ170mm raw facing inside diameter ≤Φ430mm |
| Plate type 2 diameter (optional) |
raw facing inside diameter ≥Φ95mm raw facing inside diameter ≤Φ280mm |
| Width of raw facing | 20-110mm |
| Petaline numbers | 2.6; 3.6; 4.6 |
| Main electrical engine | 3kW, 125-1250 r/min, AC380V |
| Electrical engine for thread feeding | 185W, 0-1500 r/min, DC110V |
| Plate rotary speed | 53, 68, 84 r/min |
| Output | ≥80 pcs/h for plate type 1; ≥120 pcs/h for plate type 2 |
| Thread diameter | ≤12mm |
| Size | 2040x780x1260mm |
| Weight | 760kg |
Working Principle
The up and down movement of the wiring conduit and the rotation movement of the wiring reel are carried out simultaneously according to specific rules. By changing the meshing number of the variable speed gears, three different motion patterns can be obtained, corresponding to the number of entangled petals in 2.6, 3.6, and 4.6, respectively. Start the main motor and wire feeding mechanism, adjust the wiring reel to the appropriate speed, extend the wiring reel in place, adjust the cylinder pressure, and feed the wire into the wire feeding mechanism through the inlet. The wire is then wound onto the wiring reel through the wire feeding mechanism conduit and wiring conduit. After the wire is wound, return the wiring reel to its position and use a cutting knife to cut off the winding blank. Due to the certain viscosity of the wire, under the pressure of the main cylinder of the wiring tray, the wire is bonded to each other during winding, and the blank can be well maintained.
