Customized Request Double Station Hydraulic Hot Heat Press Machine Sj646 Customization
Product Details:
| Place of Origin: | China |
| Brand Name: | TOSUN |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | Peak Season Lead Time: within 15 workdays, Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T, D/P, PayPal, Western Union, Small-amount payment |
| Supply Ability: | 1000PCS/Year |
|
Detail Information |
|||
| Model NO.: | SJ646 | Specification: | 3720*1600*2530mm |
|---|---|---|---|
| Trademark: | TOSUN | Origin: | Ningbo |
| HS Code: | 8462919000 | Supply Ability: | 500PCS/Year |
| Warranty: | 12 Months | Feature: | Automation, Precision, High Efficiency |
| Customized: | Customized | Condition: | New |
| After-sales Service: | Engineers Available To Service Machinery Overseas | Transport Package: | Wooden Case |
| Customization: | Available | Customized Request | ||
Product Description
This machine is the newest pressing equipment which adopts Taiwan of China technique. It is used for brake pad hot molding (Positive mould). The machine is applied to produce asbestos-free brake pads for light vehicles.
PLC control with touch panel. Pressure and temperature can be adjusted easily. Dependable technology.
| Description | Unit | SJ646 Double Station |
| Total Pressure | TON | 250 |
| Plate size | m/m | 540×630 |
| Stroke | m/m | 400 |
| Max. plate gap | m/m | 600 |
| Oil tank | GAL | 400 |
| Maximum pump pressure | Kg/cm2 | 210 |
| Pump power | HP | 10HP×6P×2 |
| Main hydraulic cylinder diameter | mm | Ø425 |
| Main cylinder upward speed | mm/s | ≥50 |
| Heating temperature | ºC | 60-250ºC ±5ºC |
| Support mold stroke | m/m | 120 |
| Electric heating capacity | KW | 12KW*2 |
| Machine size | m/m | 3720*1600*2530mm |
| Machine weight | Kg | 14,000 |
